Product Features
● Low latency, suitable for high-performance computing and server interconnection.
● Low insertion loss and high return loss, ensuring signal integrity.
● Plug-and-play design for easy installation and maintenance.
● Compliant with industry standards such as IEEE 802.3, SFF-8431, SFF-8436, SFF-8665, and SFF-8636.
DAC-100G QSFP 1M passive copper core high-speed cable is a cost-effective solution for short-distance high-speed data transmission in data centers. The cable uses copper cable as the transmission medium, supports a total bandwidth of 100Gbps, and is suitable for interconnection of devices within or between racks. It is widely used in connections between switches, routers, servers and other devices.
Specifications
| Cable Type | Passive Cables | Cable length | 1M |
| Compatible Models |
100G QSFP |
Interface Type |
QSFP To QSFP |
| Supply Voltage | 3.3V | Transfer Rate | 100Gbps |
| Power Consumption (W) |
≤0.1W |
Operating Temperature |
0~70° |
| Application | 1G Ethernet | Transmission Standards | Compliant with SFF-8472, SFF-8024 and SFP+ MSA standards |
